F87
YANYAO
（Core Technologies）
1. Three-wavelength Q Switch picosecond technology: 1064nm for dark tattoos such as black/blue and deep pigments, 532nm for light-colored tattoos such as red/orange, 755nm for difficult-to-remove colors such as green/purple, with pulse width ≤500ps and Q Switch trigger speed ＜10ns, shattering pigments into nano-scale fragments and reducing the risk of scarring; 2. Intelligent pigment recognition system: Built-in high-definition image acquisition module, automatically analyzes tattoo pigment composition and distribution, matches optimal wavelength and energy parameters, and improves treatment efficiency by 40%; 3. Precise energy regulation: 15-inch touch screen supports stepless adjustment of energy density (1-20J/cm²) and frequency (1-20Hz), stores 50 sets of personalized treatment programs, and supports multi-physician authority management; 4. Four-fold cooling protection: Integrating air cooling + water cooling + semiconductor + sapphire contact refrigeration, the treatment head temperature is stably maintained at 3-8℃, and the epidermal thermal damage rate is reduced to below 0.1%; 5. Professional durable configuration: The laser source has a service life of 300,000 shots, the treatment head adopts scratch-resistant quartz window, and the device has a real-time monitoring function of pigment removal rate, suitable for high-frequency diagnosis and treatment scenarios.
（Working Principle）
Based on the "Q Switch enhanced photomechanical effect", it releases high-intensity pulse energy instantly through Q Switch technology, combined with the characteristics of picosecond ultra-short pulses, to achieve efficient and safe tattoo removal:
• Wavelength targeting: 1064nm, 532nm and 755nm wavelengths form resonant absorption with different color pigments respectively, accurately locating the target tissue and avoiding damage to surrounding normal skin;
• Q Switch energy burst: The Q Switch compresses and releases laser energy within nanoseconds, forming a pulse with a peak power of 10⊃1;⊃2;W, generating a strong mechanical shock wave to shatter pigment particles into tiny fragments with a diameter of ＜100nm;
Metabolic excretion and skin repair: Tiny pigment fragments are excreted from the body through the human lymphatic system, and at the same time, picosecond pulses stimulate the activity of fibroblasts in the dermis, promote collagen
• regeneration, and reduce post-treatment pigmentation and scar formation;
• Multi-wavelength synergy: For composite pigments of color tattoos, the device automatically switches to corresponding wavelengths for step-by-step removal, improving the overall removal rate.
